• ISO/IEC 17025 Calibration
    • Per B89.4.1b-2001 and OEM specifications.
    • Measurement uncertainty for all tests.
    • Before and after results.
    • Repeatability per B89.
    • X, Y, and Z linear accuracy per B89.
    • Squareness / Perpendicularity.
    • Volumetric accuracy per B89 if OEM specifies.
    • Linear temperature compensation to 68F°.
    • Approved test sheets.
    • Approved preliminary and final certificates.
    • Approved calibration sticker.
    • Hard measurement data.
    • Meets A2LA traceability policy.
    • The quality manager reviews the final certificate.
    • Meets QS9000, ISO, and ISO/TS requirements.
    • Adjustments are made to meet OEM specifications.

    Includes preventive maintenance after the before measurements.

    • Clean and inspect fans, filters, airlines, scales, and way surfaces.
    • Check and adjust read heads and signals.
    • Inspect and adjust fine feeds, air / hard bearings, counterbalance, machine level, and failsafe.
    • Inspect power supplies for AC ripple and proper voltage.
    • Recommendations will be made for repairs if needed.
  • EOC Calibration (Not Accredited)
    • Before and after results.
    • Repeatability per B89 X, Y, and Z linear accuracy per B89.
    • Squareness / Perpendicularity
    • Volumetric accuracy (15 position ball-bar) if OEM specifies.
    • Hard measurement data.
    • Calibration sticker
    • Calibration certificate
    • Traceable to N.I.S.T
    • Adjustments are made to meet OEM Spec.

    Includes preventive maintenance after the before measurements.

    • Clean and inspect fans, filters, airlines, scales, and way surfaces.
    • Check and adjust read heads and signals.
    • Inspect and adjust fine feeds, air / hard bearings, counterbalance, machine level, and failsafe.
    • Inspect power supplies for AC
    • Ripple and proper voltage.
    • Recommendations will be made for repairs if needed.

    Servo Option

    Full Servo preventive maintenance includes:

    • Inspect motors.
    • Inspect belts and alignment of drives.
    • Check bearing wear
    • Check KV parameters
    • Check positioning
    • Check balance
    • Check slip
    • Check overshoot
    • Belt tension
    • Adjustments will be made if needed to the inspected items.
    • Recommendations will be made for repairs if needed.
  • Factory Calibration (Not Accredited)
    • No before measurements.
    • Repeatability per B89 X, Y, and Z linear accuracy per B89.
    • Squareness / Perpendicularity
    • Volumetric accuracy (15 position ball-bar) if OEM specifies.
    • Hard measurement data.
    • Calibration sticker
    • Calibration certificate
    • Traceable to N.I.S.T
    • Adjustments are made to meet OEM specifications.

    Includes preventive maintenance before measurements are taken.

    • Clean and inspect fans, filters, airlines, scales, and way surfaces.
    • Check and adjust read heads and signals.
    • Inspect and adjust fine feeds, air / hard bearings, counterbalance, machine level, and failsafe.
    • Inspect power supplies for AC ripple and proper voltage.
    • Recommendations will be made for repairs if needed.

    Z Roll Option

    • Z-Axis Roll Performance Test.
    • Recommended for customers who utilize long offset probe extensions.
